Through Hole (DIP) Diode
5819 0.5MM
Product Name: 1N5819 SMD Diode 0.5MM
Package Size: 0.5MM (Specify actual SMD package, e.g., SOD-123 or SMA)
Reverse Voltage (VR): 40V
Application: Suitable for high-speed switching, low forward voltage drop applications such as power supplies, reverse polarity protection, and DC-DC converters.
(Excluding Tax)
1N5819 SMD Diode – 40V Schottky
Efficient Switching for Compact Power Circuits
The 1N5819 SMD Diode is a fast-recovery Schottky diode designed for high-efficiency switching with low forward voltage drop. Packaged in compact 0.5MM SMD (e.g., SOD-123), it supports space-constrained designs while ensuring optimal performance.
- Reverse Voltage: 40V
- Package: 0.5MM SMD (SOD-123 / SMA)
- Low forward voltage drop for energy-efficient operation
- Fast switching response for improved circuit speed
- Ideal for space-saving designs in compact PCBs
Applications
- Switch-mode power supplies (SMPS)
- DC-DC converters
- Reverse polarity protection
- Battery-powered devices
- General-purpose fast switching
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | 1N5819 SMD Diode |
| Package Size | 0.5MM (e.g., SOD-123, SMA) |
| Reverse Voltage (VR) | 40V |
| Application | High-speed switching, low forward voltage drop, polarity protection |
| Mounting Type | SMD |
Order 1N5819 SMD Diodes in bulk from Edzeal for cost-effective and reliable electronic manufacturing solutions.
Based on 0 reviews
Be the first to review “5819 0.5MM”
