229MD FAST CHARGING PROTOCOL IC

Model Number: HC2702B

Brand: HCW

Package Type:  SOP-8

Power Output: 5W

Function: AC to DC Converter

Application: Mobile Chargers, Power Adapters, LED Drivers

Input Voltage: 100V-264V

Output Voltage: 5V

Output Current: Up to 1.2A (based on design).

Protections: Built-in Overload, Short Circuit, and Thermal Protection

Operating Temperature Range: -45°C to 125°C

Model Number: HC2705B

Brand: HCW

Package Type: SOP-8

Power Output: 5W

Function: AC to DC Converter

Application: Mobile Chargers, Power Adapters, LED Drivers

Input Voltage: 100V-264V

Output Voltage: 5V

Output Current: Up to 1A (based on design).

Protections: Built-in Overload, Short Circuit, and Thermal Protection

Operating Temperature Range: -45°C to 140°C

Model Number: HC2702D

Brand: HCW

Package Type: SOP-8

Power Output: 10W

Function: AC to DC Converter

Application: Mobile Chargers, Power Adapters, LED Drivers

Input Voltage: 100V-264V

Output Voltage: 5V

Output Current: Up to 2.1A (based on design)

Protections: Built-in Overload, Short Circuit, and ALOP

Operating Temperature Range: -45°C to 125°C
